Waukesha 9390 Intake Valve Guide (1408011)
WAUKESHA V16, 9390 C.I., (153.9L), P9390G BORE - 238.125mm/9.375"
SBI - Valve Guides - 140-8011 - Intake; 0.5550 I.D.,5.188 Length,1.0025 O.D.,Late Type, Guides Must Be Reamed In Place To .5608/.5615. Always Press Wet Guide Out Toward Valve Seat And In From Valve Seat Side
Specifications
Inner Diameter - 0.5550
Outer Diameter - 1.0025
Length - 5.188
Interchanges
Ertel - 8011
Pioneer - 08011
Waukesha - 204109E
